Quick Details
• Lock Dimension:L500*W58*H25mm
• Armature Plate Dimension: L158*W43*H11mm
• Input Votage DC12V+10% or DC24V+10%
• Working Current: 12V/1200mA or 24V/600mA
• Holding Force:350KGx2（800Lbsx2)
• Surface Temp: ≤ +20℃ (Based on ambient temperature)
• Operating Temp: -10~+55℃(14-131F)
• Humidity: 0~90%(non-condensing)
• Weight: 4.2KG
• Bracket Optional:B -350ZL/350Z/350L
• LED Status: Red(Open),Green(Close)
• Door status signal output for optional
• Time delay seting: 0/3/6/9 seconds for optional
